Network Parameters
Port Number8 × 10/100 Mbps PoE ports, and 1 × Gigabit RJ45 port
Port TypeRJ45 port, full duplex, MDI/MDI-X adaptive
Working Mode
Standard mode (default)

Extend mode

StandardIEEE 802.3, IEEE 802.3u, IEEE 802.3x, and IEEE 802.3ab
Forwarding ModeStore-and-forward switching
MAC Address Table16 K
Internal Cache4 Mbits
Switching Capacity3.6 Gbps
Packet Forwarding Rate2.6784 Mpps
PoE Power Supply
PoE StandardIEEE 802.3af, IEEE 802.3at
PoE Power Pin
End-span: 1/2(-), 3/6(+)

Mid-span: 4/5(+), 7/8(-)

8-pin power: 1/2(-), 3/6(+), 4/5(+), 7/8(-)

PoE PortPorts 1 to 8
Max. Port Power30 W
PoE Power Budget110 W
Software Function
Port ConfigurationSupport rate, flow control, and switch configuration
Device MaintenanceSupport remote upgrade, recovering default parameters, viewing logs, configuring basic network parameters.
PoE FunctionIEEE 802.3at/af device provides power supply.
PoE Configuration
PoE watchdog: Ports 1 to 8 auto detect and restart the cameras that do not respond.

PoE enabling: Support

General
ShellMetal material, fan-free design
Net Weight0.35 kg (0.77 lb)
Gross Weight1.114 kg (2.45 lb)
Dimension (W × H × D)170 mm × 27.6 mm × 93.1 mm (4.76” × 3.47” × 1.09”)
Operating Temperature0°C to 40°C (32°F to 104°F)
Storage Temperature-40°C to 85°C (-40°F to 185°F)
Operating Humidity5% to 95% (no condensation)
Relative Humidity5% to 95% (no condensation)
Power Supply48 VDC, 2.5 A
Max. Power Consumption120 W
Approval
EMCFCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 55024: 2010 +A1: 2015); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016)
SafetyUL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013)
ChemistryCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No.1907/2006)
