Standart ve Protokol
IEEE802.3, IEEE802.3u, IEEE802.3ab
Arayüzler
1*10/100/1000Mbps WAN port
3*10/100/1000Mbps LAN ports
Anten
5*external antennas
Buton
1*WPS/Reset button
Güç
Input: AC 100-240V~50/60Hz
Output: DC 12V1A
LED Göstergesi
1* LED
Boyut
244*56*200mm(L*W*H)
Kablosuz
Kablosuz Standart
IEEE 802.11ax/ac/n/a 5 GHz
IEEE 802.11n/b/g 2.4 GHz
Veri hızı
5GHz:1201Mbps
2.4GHz:300Mbps
Frekans
CE:
2.4G: 2412-2472MHz(CH1-CH13)
5G: 5180-5240MHz(CH36-CH64)
FCC:
2.4G: 2412-2462MHz(CH1-CH11)
5G: 5150-5250MHz(CH36-CH64)
5725-5850MHz(CH149-CH165)
İletim Gücü
CE:
<20 dBm (2.4 GHz)
<23 dBm (5 GHz)
FCC:
<30 dBm (2.4 GHz)
<30 dBm (5 GHz)
Temel özellikler
OFDMA+MU-MIMO
Beamforming Signal Directional Transmission Technology
Kablosuz Güvenlik
WPA2-PSK,WPA3-SAE,WPA3-SAE/WPA2-PSK
Wireless Encryption Disable and Enable
WPS Fast Connection
Yazılım
İnternet Bağlantı Türü
PPPOE, Dynamic IP, Static IP
Network Protocol
IPv4&IPv6
Çalışma Modu
Wireless Relay Mode (Client+AP)
Parental Control
Client Filter
Remote Web Management
DHCP
DHCP Server
DHCP Client List
DHCP Static IP Address Reservation and Assignment
Virtual Server
Port Forwarding, DMZ Host, UPnP
Güvenlik
Güvenlik Duvarı
ICMP Flood Attack Defense
TCP Flood Attack Defense
UDP Flood Attack Defense
Ignore Ping Packet From WAN Port
DDNS
Support DynDNS, No-ip
VPN
IPSec Transparent Transmission
PPTP Transparent Transmission
L2TP Transparent Transmission
PPTP VPN Server
PPTP VPN Client
L2TP VPN Client
Seçkin Özellikler
Wi-Fi+(Mesh System)
IPTV
IPv6
Smart LED on/off
Other Function
Smart Power Saving
Bandwidth Control
Guest Network
System Log
MAC Clone
Broadband Account Migration
Tenda App(Parental Control)
Backup & Restore Configurations
Support Automatic Access Detection
Upgrade Online
Diğer
Sıcaklık
Operating Temperature : 0?~40?
Storage Temperature : -40C ~70?
Nem
Operating Humidity : 10 %~90% RH non-condensing
Storage Humidity : 5 %~ 90%RH non-condensing
Varsayılan Ayarlar
Sertifikasyon
CE, FCC,RoHS
EIRP Gücü (Maks)
Paket İçeriği
Dual Band Gigabit Wi-Fi 6 Router*1
Ethernet Cable*1
Power Adapter*1
Installation Guide*1
