TEIRP Power (Max.) 2.400-2.4835GHz:19.86dBm (EIRP)
5.150-5.250GHz:22.96dBm (EIRP)
Standart IEEE802.3, IEEE802.3u,IEEE802.3ab
Arayüz 1*10/100/1000Mbps WAN port
3*10/100/1000Mbps LAN ports
Anten 7*6dBi harici anten
Buton 1* WPS/Reset button
Güç Giriş:AC 100-240V~50/60Hz 0.6A
Output:DC 12V1.5A
Boyut 238.9*144.3*40.3mm
LED Sys*1,WAN*1, LAN*1,WiFi/WPS*1
Kablosuz Standartlar IEEE 802.11ac wave2/a/n 5GHz
IEEE 802.11b/g/n 2.4GHz
Kablosuz Hız 5GHz: Up to 1733Mbps
2.4GHz: Up to 300Mbps
Sıklık Simultane çift bant 2.4 & 5GHz
İletim Gücü CE:
<20dBm(2.4G)
<23dBm(5G)
FCC:
<30dBm
Temel Özellikler SSID Broadcast: Enable/Disable
Transmission Power: high, medium, low
Beamforming
MU-MIMO
Kablosuz Güvenlik WPA-PSK/WPA2-PSK, WPA/WPA2
Wireless Security: Enable/Disable
WPS(WiFi Protected Set-up) fast encryption
İnternet Bağlantı Türü PPPoE, Dynamic IP, Static IP
PPPoE(Russia), PPTP(Russia), L2TP(Russia)
Çalışma Modu Wireless Router Mode
Universal Repeater Mode
WISP Mode
DHCP Sunucusu DHCP Server
DHCP Client List
DHCP Reservation
Sanal Sunucu Port Forwarding
DMZ Host
UPnP
Güvenlik Client Filter
Parental Control(support black list and white list)
Remote Web Management
Firewall Forbid UDP flood attack
Forbid TCP flood attack
Forbid flood attack
Forbid WAN PING from internet
DDNS Support DynDNS, Oray.com, 88ip
VPN IPsec pass through
PPTP pass through
L2TP pass through
PPTP server
PPTP client
L2TP client
Special Features Smart Traffic Prioritisation
PPPoE Username/password Clone
Smart WiFi Schedule
Smart Power Saving
Smart LED on/off
Tenda Cloud
Tenda App
Diğer Bandwidth Control
IPTV
MAC Clone
Static Routing
System Log
Backup & Restore configurations
Firmware upgrade online
Firmware upgradeable via browser
Supports IPv6
Sıcaklık Operating Temperature: 0C ~ 40C
Storage Temperature: -40C ~ 70C.
Nem Operating Humidity:10% ~ 90% RH non-condensing
Storage Humidity: 5% ~ 90%RH non-condensing.
Varsayılan Ayarlar Default Access: tendawifi.com
Belgeleme CE/FCC/RoHS
Paket İçeriği Wireles Router*1
Power Adapter *1
Install Guide*1
Ethernet Cable*1
